PCB Factory: Pioneering Technological Progress

The PCB (printed circuit board) photosensitive process is a key step that uses light to transfer circuit images onto the printed circuit board. Professional PCB factory, with advanced equipment and rich experience to perform this task. The photosensitive process begins by creating an image of the circuit on a computer and converting that image into a format that can be read by a lithography machine. Once the image is created and transformed, it can be transferred to a printed circuit board containing light-sensitive material. When exposed to strong ultraviolet light, light-sensitive materials begin to harden. The parts that are not exposed to ultraviolet light are washed away, leaving behind an image of the hardened circuit. SprintPCB's photosensitive process is not only accurate but also efficient, enabling the rapid production of high-quality printed circuit boards, using the latest equipment and technology to ensure that each board meets customer needs and standards.

One of the major problems in PCB manufacturing is the generation of hazardous waste, and chemicals used in the production process, such as etchers and solvents, can be harmful if not handled properly. We implement a comprehensive waste management system that reduces the generation of hazardous waste and ensures that all waste is treated and disposed of responsibly. Our plants are designed with energy efficiency in mind. Our production equipment is optimized to reduce energy consumption, and we use energy efficient lighting and heating systems throughout the facility. The SprintPCB plant is committed to sustainability in all aspects of our operations.

PCB factories understand the importance of photomask in ensuring the quality and performance of the board, photomask is a clear plastic sheet covered with a pattern that blocks light. This pattern is an exact replica of the circuit board design. During lithography, a photomask is placed on a circuit board containing a light-sensitive material. The board is exposed through a photomask, allowing light from the patterned part to penetrate and affect the board.
Use the most advanced equipment and technology to manufacture and verify their photomasks. Ensure that each photomask matches the design document exactly and remains intact throughout the production process. This ensures that each board accurately reflects the design intent and meets the highest standards of performance.

In the manufacturing process of PCB (printed circuit board), surface treatment this process involves performing a series of treatments on the surface of the circuit board to improve its performance and durability. A professional PCB factory with advanced equipment and rich experience to perform. The surface treatment will clean the circuit board to remove any impurities and residues that affect the surface treatment effect. A variety of surface treatments, including organic protective coatings (OSP), nickel gold (ENIG), photodeposited hard gold (ISIG), and tin immersion (HASL). Each of these approaches has its own advantages and features that can meet different performance requirements and budget constraints. No matter which surface treatment method is chosen, SprintPCB ensures that it is performed accurately and thoroughly. Use the latest equipment and technology to ensure that every board receives an even, long-lasting, high-quality finish.
