We Have The Best Solutions for Your Business
SprintPCB provides one-stop and competitive PCB and PCBA manufacturing services to clients worldwide.
We can provide competitive prices and guarantee the quality requirements of customers without excess quality. Our technical level can meet most of the industrial control and consumer products.
SprintPCB promises product safety with IATF16949, ISO 9001, ISO 14001 ,and UL certifications.
Reflow furnaces in PCBA assembly of SprintPCB
A reflux furnace is a device used to weld electronic components to a circuit board that provides uniform and precise heating, thus ensuring the quality and reliability of the solder joints. Any small mistake can cause the board to not work properly. When the circuit board is placed in a reflux furnace, the circuit board is uniformly heated to a specific temperature, causing the solder to melt and secure the components. This method can provide very strong and reliable solder joints, and SprintPCB's reflow furnace technology allows us to provide high quality, efficient and reliable PCBA assembly services.
SMT and THT hybrid technology in PCBA assembly of SprintPCB
PCBA assembly using a hybrid technology of surface mount technology (SMT) and through-hole technology (THT), this hybrid technology takes full advantage of the respective advantages of SMT and THT to handle a variety of complex and challenging PCBA assembly projects. SMT is used first to mount small and lightweight electronic components onto the circuit board. Use THT to insert large, heavy, or high-power components onto a circuit board. SprintPCB's hybrid SMT and THT technology enables us to provide high-quality, efficient and reliable PCBA assembly services. Our professional team is committed to providing the highest quality service to meet all the needs of our customers.
Mechanical and electrical connections in PCBA assembly
Strong mechanical connections are essential to withstand external forces, prevent components from shifting, and contribute to effective heat dissipation. Electrical connections are essential to establish proper circuit function. Enables signal and power flow between different components on the PCB, ensuring seamless operation. Precise electrical connections minimize signal loss, impedance mismatch, and noise interference to optimize the performance of electronic devices.
Through-hole technology (THT) in PCBA assembly of SprintPCB
PCBA assembly using Through-hole technology (THT) A technique in which pins of electronic components are inserted into pre-drilled holes in the circuit board and then welded. More complex and time consuming than surface mount technology (SMT), it can provide stronger mechanical connections and is particularly suitable for handling large, heavy or high-power components. The pin of the electronic component is inserted into the hole on the circuit board using professional equipment, and the component is fixed to the circuit board using wave soldering technology. In this process, the board is sent over a crest containing molten solder, which allows the solder to flow along the pin of the component and cool to solidify, creating a solid solder joint. SprintPCB's THT technology enables us to handle a wide range of complex and challenging PCBA assembly projects. Our professional team is committed to providing the highest quality service to meet all the needs of our customers.
Frequently Asked Question
Do you have any question?
We offer a wide range of PCBA assembly services including surface mount technology (SMT), through-hole technology (THT), and mixed technology.
We accept orders of all sizes, from prototype to large-scale production runs.
Our lead times vary depending on the complexity of the assembly and the quantity ordered.
Yes, we stand by the quality of our products and offer warranties based on the specific product and application.
Yes, our team of skilled engineers and technicians are well-versed in handling complex PCBA designs.
Yes, we can assist with design layouts and provide suggestions for improving manufacturability and cost-effectiveness.
We have a rigorous quality control process that includes visual inspection, electrical testing, and AOI (Automated Optical Inspection).
Yes, we comply with all relevant environmental regulations including RoHS and REACH.
Yes, we can provide references upon request.
Yes, we offer both SMT and THT as well as mixed technology for PCBs that require both.
